9FZ-45
Product Description
9FZ-35, 45 Self-priming Cyclone Grinder
The disc grinder is suitable for fine powders including corn, straw, wheat, pepper, turmeric, herbs, herbs and more. The particle size of the powder is about 60-100 mesh. This grinder crushes wet and dry granular produce for delicious meals. This type of disc corn grinder is widely used to grind various materials, such as corn, beans, wheat, rice, sorghum and other miscellaneous grains and medicinal materials. It is an ideal grinder. Machines for processing grain, animal feed, spices, etc. This model is very suitable for small workshops and household use, and can also be used in pharmaceutical, chemical, pesticide, food, grain and other industries.
Our disc mills are widely used in the grinding of corn, maize, soybeans, sorghum, dried sweet potato slices and bean cakes and other grains and feeds. In addition to the above uses, it can also be used for rapid beating of pulp, reduction of chemical raw materials, Chinese herbal medicines and wet grinding of water-containing foods, such as fresh fruits, sweet potatoes, wet soybeans, etc.
Specification
model | 9FZ-45 Automatic Grinder | model | 9FZ-35 Automatic Grinder |
Rotating speed | 3200r/min | Sieve width | 120mm |
Rotor diameter | 450mm | Sieve length | 1330mm |
Screen ring diameter | 508mm | Screen ring diameter | 424mm |
Sieve size | 1600*155 | Rotating speed | 4000r/min |
productivity | ≥3000kg/h | Flat teeth | 5 |
Flat teeth | 6 | square teeth | Long 2 short 9 |
square teeth | 12 | wind blade | Big 5 Small 5 |
Power consumption per ton of | ≤18KW.h/t | supporting power | 11KW |
material | 380v | Yield | ≥1000kg |
Voltage | 18.5kw (level 4) | weight | 140kg |
rated power | Feed hopper Two sets of sieve rings | ||
Accessories | and sieves | ||
Dimensions (mm) | 520*400*575 | ||
Packing size (mm) | 1110*630*1280 | ||
weight | 220kg |
feature
1) New design structure, simple structure, convenient installation and maintenance.
2) Adopt advanced tooth disc grinding technology to obtain high-quality powder.
3) The powder mesh size can be 0.06mm, 1.2mm, 3.5mm according to customer requirements.
4) The operation is highly automated, the work is stable, and the downtime rate is extremely low or other failure problems.
5) Small size and large capacity, suitable for commercial scale production.
6) Low investment, high return.
Packing: export standard container wooden box or pallet or bare package;
Company Profile
Henan Sunshine Industry Co., Ltd. specializes in the production of feed equipment (including poultry feed, ruminant feed, aquatic feed, pet feed) and biomass pellet equipment. Our products have been highly recognized by customers in the United States, Canada, Europe, India, South America, Southeast Asia, South America and other regions. We attach great importance to reputation and contract, and have won the market and won the praise of domestic and foreign customers. The company always adheres to the quality of customer service.
transportation:
All machines will be sent by sea, if you need other shipping methods, please inform us in advance. Before and after shipment, we will
Take a picture of the machine and send the picture to the customer.
Technical Service:
1.Design for production line flow and equipment layout freely according to the site.
2.Supply the foundation drawing of equipment and drawing of parts made by buyer
3.Supply the technical parameters of peripheral equipment.
4.During the operation,we can offer the technology service freely if the user needs to adjust the layout and application.
5.During the operation, we only collect the cost if the user willing to upgrade the equipment when we have the advantage technology.
After-sales service
1. During installation and debugging, send technicians to the site to guide installation and debugging.
2. During the installation and commissioning process, we provide training services
3. The quality assurance date is one year after commissioning.
4. If the equipment fails due to improper handling by the user, we will be responsible for the maintenance and charge the corresponding fee.
5. We provide components with favorable price, lasting maintenance. After the quality assurance period, if the equipment needs to be repaired, we only charge the cost price.
