ZC900
Product Description
Product Details
It integrates the functions of blade cutting, high-speed air impact and collision, and can simultaneously complete the sorting and processing of trace materials.
advantage:
1). Double air inlet design: solve the log and miscellaneous wood at one time, and standardize the production process to ensure worry-free use;
2). Manganese steel thickening hammer: using new laser cutting technology, thickening material, high efficiency;
3). Ultra-wide cast steel wear-resistant lining plate: integral molding, cast steel die-casting process, using fast lining plate, high precision;
4). High hardness screen: corrosion-resistant honeycomb screen, not easy to break, better discharge effect
Model | ZC-420 | ZC-500 | ZC-600 | ZC-700 | ZC-900 |
Knives (pcs) | 4pcs | 4pcs | 4pcs | 6pcs | 8pcs |
Output(t/h) | 1-1.3t/h | 1.5t/h | 2t/h | 2.5t/h | 3-4t/h |
Power(kw) | 7.5-11kw | 18.5kw | 30kw | 37kw | 55kw |
Weight(kg) | 240kg | 420kg | 510kg | 670kg | 1100kg |
Dimension(m) | 1350*750*990 | 1.5*0.75*1.05 | 1.6*0.75*1.1 | 1.8*0.85*1.2 | 1.95*1.1*1.3 |
1. Manganese steel quenched cutter head
Thickened cutter head, strong and powerful, not easy to break
2. High quality bearings
Imported bearings, made of stainless steel, durable.
3. Two feed ports
Two feed openings, wooden straw for easy handling
4. Thickened manganese steel screen
Thickened screen, sun protection and durable, size can be customized
Five-star brand motor, pure copper motor
One-year warranty, worry-free after-sales
Large and small pieces of wood can be broken
Various models to choose from
The bigger the feed port, the bigger the broken wood
It can pulverize logs, branches, shrubs, bamboo, straw, bark, peanut shells, corncob, wheat straw, straw and other wood into sawdust or sawdust.
Company Profile
Henan Sunshine Industry Co., Ltd. specializes in the production of feed equipment (including poultry feed, ruminant feed, aquatic feed, pet feed) and biomass pellet equipment. Our products have been highly recognized by customers in the United States, Canada, Europe, India, South America, Southeast Asia, South America and other regions. We attach great importance to reputation and contract, and have won the market and won the praise of domestic and foreign customers. The company always adheres to the quality of customer service.
Delivery service
Shipping: LCL by sea, FCL by sea.
Packing: Export wooden box packing or container loading.
Delivery time: 3-7 days, after deposit, special circumstances will be notified separately.
Shipping: We can take care of shipping and also accept customer shipping agents.
Shipping Port: Tianjin, Qingdao, Shanghai, Guangzhou, etc.
Technical Service:
1.Design for production line flow and equipment layout freely according to the site.
2.Supply the foundation drawing of equipment and drawing of parts made by buyer
3.Supply the technical parameters of peripheral equipment.
4.During the operation,we can offer the technology service freely if the user needs to adjust the layout and application.
5.During the operation, we only collect the cost if the user willing to upgrade the equipment when we have the advantage technology.
After-sales service
1. During installation and debugging, send technicians to the site to guide installation and debugging.
2. During the installation and commissioning process, we provide training services
3. The quality assurance date is one year after commissioning.
4. If the equipment fails due to improper handling by the user, we will be responsible for the maintenance and charge the corresponding fee.
5. We provide components with favorable price, lasting maintenance. After the quality assurance period, if the equipment needs to be repaired, we only charge the cost price.
